ML63Q2537-NNNGD(Tray) (In Entwicklung)
Solist-AI™, 32-bit Microcontroller (Arm® Cortex®-M0+)
ML63Q2537-NNNGD(Tray) (In Entwicklung)
Solist-AI™, 32-bit Microcontroller (Arm® Cortex®-M0+)
The ML63Q2537 is a MCU equipped with a 32-bit Arm® Cortex®-M0+ processor and an AI accelerator, "AxlCORE-ODL". It also integrates a variety of peripheral circuits, including CAN FD controller, 3-phase motor control PWM, two A/D converters, analog comparators, I²C, SPI, and UART. With a low power consumption of approximately 40mW during AI processing, this makes it an optimal solution for predictive failure detection in industrial equipment and home appliances.
Among the lineup, this product features a 256KByte ROM capacity, a 48pin package.
Produktdetails
Spezifikationen:
Operating Voltage (Min.)[V]
2.3
Operating Voltage (Max.)[V]
5.5
CPU Core
32bit Arm®Cortex®-M0+
ROM type
Flash
ROM Capacity [Byte]
256K
Data Flash Capacity [Byte]
8K
RAM Capacity [Byte]
16K
Input/Output
34
Operating Frequency (Max.) High Speed
48MHz(PLL oscillation)/ 40MHz(Crystal oscillation)
Operating Frequency (Max.) Low Speed
32.768kHz(Internal RC oscillation/Crystal oscillation)
Minimum Instruction Execution Time
20.83ns@48MHz/ 30.5μs@32.768kHz
Current Consumption (Typ.@HALT)
3.5μA(Internal RC oscillation)
Operating Temperature (Min.)[°C]
-40
Operating Temperature (Max.)[°C]
105
AI Accelerator
AxlCORE-ODL
1kHz Timer
1
16bit Timer
6
16bit Multi Functions Timer
2(TMR, PWM, Capture)
WDT
1
ADC (method)
12bit×12ch, 2unit (SA type)
I2C
Master/Slave×1
SSIO
2
UART
Full Duplex×4
Supply Voltage Detection
VLS×1
CAN
1
External Interrupt Sources
8
Others
3 phase motor control PWM×1,
Comparator×3, DMA
Halogen Free Support ?
Yes
Industrial Grade ?
Yes
Automotive Grade
No
Development Support
-
- Reference Board
- RB-D63Q2537TB48
- Supply Status
- Recommended
- Board size (mm)
- W56 × D94 × H12
- Supported MCUs
- ML63Q2534
- ML63Q2537
- Structure
- ML63Q2537 (48PIN TQFP) Reference Board
