PSR100KTQFF0L50

6432 (2512) size, 8 W, 0.5 mΩ, Ultra-Niederohm-Metallplatte / Shunt-Widerstand für hohe Leistungen.
Data Sheet Kaufen
PSR100KTQFF0L50

PSR100KTQFF0L50
6432 (2512) size, 8 W, 0.5 mΩ, Ultra-Niederohm-Metallplatte / Shunt-Widerstand für hohe Leistungen.

Die Serie PSR100 ist ideal für die Stromerfassung in Hochstromschaltungen.

Optimized for a variety of applications, from wearable devices to automotive systems and industrial equipment

Data Sheet Kaufen
Data Sheet Kaufen

Lineup


* Fractions not supported (decimals only)

Produktdetails


Teilenummer | PSR100KTQFF0L50
Status | Empfohlen
Gehäuse | PSR100
Gehäusetyp | Taping
Einheitenmenge | 5000
Minimale Gehäusemenge | 5000
RoHS | Ja
Product Longevity Program | 10 Years

Spezifikationen:

Automotive grade

Yes

Size[mm](inch)

6432(2512)

Rated Power[W]

8, 4

Resistance Tolerance

F (±1%)

Resistance range[Ω]

0.5m

Temperature Coefficient[ppm/°C]

0～+100

Operating Temperature[°C]

-65 to 175

Type

For current sensing

Operating Temperature (Max.)[°C]

175

Common Standard

AEC-Q200 (Automotive Grade)

Find Similar

Eigenschaften:

  • Excellent TCR characteristic
  • Convex structure
  • ROHM resistors have obtained ISO9001 / IATF16949 certification.
  • Corresponds to AEC-Q200.
